Page 10
SET UP & USE
INSTALLING THE EXHAUST CONNECTOR
Install the exhaust connector as shown in the illustration by lining it up with the connector
on the back of the dryer and turning it clockwise so the tabs on the exhaust connector
fit into the slots on the connector:
• For a downward exhaust, join the sections (1) pointing downward.
• For an upward exhaust, join the sections (2) pointing upward.
NOTE: The dryer must be vented. A ventilation kit with a 4" diameter duct
can be purchased at your local hardware store.
