Black+Decker CTO650 - Control Panel

17
16
1. Toast and Bake/Broil Temperature control knob ( HORNEAR / ASAR) or
( BAKE / BROIL)
2. 60-minute bake timer
3. On indicator light
4. Side handle
5. Toast browning control knob ( TOSTAR) or ( TOAST)
† 6. Slide rack (Part # CTO650-91)
† 7. Slide-out crumb tray (Part # 4850)
8. Door handle
† 9. Bake pan (Part # 46)
† 10. Broil rack (Part # 43)
11. Extra-deep curved interior
Note: † indicates consumer replaceable/removable parts
Product may vary slightly from what is illustrated.
10
9
8
7
6
5
4
3
2
1
11
Important:
When using the TIMER
function, always turn the dial
past 20 and then turn back or
forward to desired setting.
ENGLISH
1. Toast and Bake/Broil Temperature control knob ( HORNEAR / ASAR) or
( BAKE / BROIL)
2. 60-minute bake timer knob
3. On indicator light
4. Toast browning control knob ( TOSTAR)
3
1
2
4
CONTROL PANEL
TOAST
OFF
LIGHT
MEDIUM
DARK
ON
BAKE TIMER
BROIL
TOAST
BAKE / BROIL
180
3
1
2
4
120 V
220 V
