Blackstar Series One
 Live Logic MIDI output  Series One MIDI input
 Patch mode - changing channel on your Series One (Set patch mode display
to offset)
 Custom mode  Download the Series One Template from
https://www.blackstaramps.com/uk/ranges/live-logic/usb-midi-controller to
change patch with two switches left blank for other MIDI equipment.
DAW plugin control
 Live Logic USB ---> PC/MAC
English
10
Strymon Nixie control
 Live Logic USB  PC/MAC
 Live Logic MIDI Out  Strymon Midi In
 Strymon Midi Out  Live Logic Midi in
Live Logic Midi Thru set to Off.
MIDI Interface
 Live Logic USB  PC/MAC
 External Midi Hardware MIDI OUT  MIDI IN
 External Midi Hardware MIDI IN  MIDI OUT
 Live Logic Midi Thru set to Off
 Add Expression pedals to Live Logic to control DAW or external MIDI equipment.
English
11
