8
DESCRIPTION OF THE CONTROLS
HOB GAS BURNER KNOB (A)
By rotating the knob in an anticlockwise
direction, the following symbols appear:
= Closed position
= “Full on” position
= “Reduced rate or Low” position
OVEN ELECTRIC THERMOSTAT KNOB
(B)
By turning the oven knob clockwise we
values (from 50°C to Max).
OVEN FUNCTION SELECTOR KNOB
(4) (C)
By turning the knob to the right or to the
0 = Oven off
= Oven light on, which stays on for all
functions
= Defrost
= Fan Forced (Rear heating element
and fan on)
= Grill heating element
Note:The grill element symbol above is
slightly different to the symbol on the
oven.
C
A
B
DESCRIPTION OF THE APPLIANCE
