24
INSTRUCTIONS FOR THE INSTALLER
Drill two holes in the wall
for each bracket accor-
ding to the g. 2 and x
the bracket.
Hose Restraint Chain
The installer must t a chain, no more than 80% of the hose length to ensure
that there is no strain on the hose when the cooker is pulled forward. Attach
one end of the chain as close as possible to the gas inlet on the cooker and
the other end as close as possible to the gas outlet on the wall. Suitable
chain and ttings are to be supplied by the installer.
Mark it the same dis-
tance, (X) on back wall.
IMPORTANT: After tting the stablising brackets and pushing the cooker
into position, check that the cooker does not tilt forward or sideways
Push back the cooker
against the wall.
