ELECTRONIC SPECIFICATION
Protocol RC5
Operation Voltage DC 1.9V to 3.4V
Transmission Medium IR 38 kHz
Standby current 10uA max
Operation current 30 mA max
Distance and angle Distance: ≥ 5.6 m
Left/Right: ±30°
Up/Down: ±15°
ENVIRONMENTAL SPECIFICATION
Operation temperature 0°C to 50°C
Storage temperature -20°C to 60°C
MECHANICAL SPECIFICATION
Keys Operating life 300,000 strokes
Evaluation Criteria Light: 750 lux +/- 250
Time to validate: 10 seconds
Key pull force 1000 grams
Drop Test Height 1 m
Battery Door Type Latch
PHYSICAL SPECIFICATIONS
Length/Width/Thickness 167х42х17 mm
Weight 53 g
Case material ABS plastic
Keypad material Silicone
Packaging PET bag
STANDARDS
Certification Requirement CE
Environmental
Requirements
RoHs, WEEE, CE
VISUAL SPECIFICATION
Number of keys 40 keys
Battery type 3 volts, 2x AAA
Battery Life 1 year (normal usage)
IR LEDs One, 5 mm AA White LED
SPECIFICATIONS
SRC-4015-1
