2-CORE PLUG
Live
(Brown)
Earth
(Green &
Yellow)
Neutral
(Blue)
Neutral
(Blue)
Live
(Brown)
WARNING: Do not connect either
wire to the earth terminal.
This symbol indicates that this 2-core
appliance is Class II and does not
require an earth connection.
The wire coloured blue must be
connected to the terminal marked with
the letter N or coloured black.
The wire coloured brown must be
connected to the terminal marked with
the letter L or coloured red.
3-CORE PLUG
WARNING: This appliance must
be earthed.
The wire coloured green and yellow
must be connected to the terminal
marked with the letter E, or by the
earth symbol, or coloured green or
green and yellow.
The wire coloured blue must be
connected to the terminal marked with
the letter N or coloured black.
The wire coloured brown must be
connected to the terminal marked with
the letter L or coloured red.
