6.
Ausbau • Removal • Demontage • Desmontaje •
Desmontagem • Pelepasan
1.
2.
3.
1.
2.
7.
12V
*
AB
Påslagen strömförsörjning +12 V / max. 150 mA
NC
Telefon: ljuddämpning
NC
Permanent +12V
Bilantenn *
Belysning
Kl.15/Tändning
Grund
Högtalare ut RR+
Högtalare ut RR-
Högtalare ut RF+
Högtalare ut RF-
Högtalare ut LF+
Högtalare ut LF-
Högtalare ut LR+
Högtalare ut LR-
