Blaupunkt GTb 8200 A - Connection Diagram

GTb 8200 A
24
Anschluss • Connection • Raccordement • Conexión • Ligação • Collegamento • Podłączenie •
Připojení • Подключение • Racordare • Свързване • Priključak • Priklop
LINE IN
RL
70 Hz 190 Hz
X-OVER
POWER
FUSE 7.5A BAT REM GND
1061 343 495 001
Made in China
INPUT
RCA
HIGH
0° 180°
PHASE
MIN MAX
GAIN
L–
R–
L
+
R
+
GTb 8200 A • Powered Subwoofer System • 200 Watts
1
2
3
7
11
8
9
10
12
5
4
6
+
12V
+12V
GROUND
max. 30cm
(
FUSE
)
+12 V
12 V
