Blaupunkt Hamburg CD70 Installation Instructions

112
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
C
B
A
14
7
10 13
16
19
3
6
9
12
15
18
2
58
11
14 17
20
C-1 C-2 C-3
RC 08 / RC 10 / RC 10H
AB
1—1 Speaker out RR+
2 Telefon Mute 2 Speaker out RR-
3 Sub Out 3 Speaker out RF+
4Permanent +12V 4 Speaker out RF-
5Aut. antenna 5 Speaker out LF+
6 Illumination 6 Speaker out LF-
7 Kl.15/Ignition 7 Speaker out LR+
8 Ground 8 Speaker out LR-
C
C1 C2 C3
1 Line Out LR 4V/10K 7 - 13 TMC/Changer Bus-In
2 Line Out RR 4V/10K 8 - 14 TMC/Changer Bus-Out
3 Line Out Ground 9 - 15 -
4Line Out LF 4V/10K 10 RC +12V 16 12V
5Line Out RF 4V/10K 11 Remote Control 17 TMC / Cha. GND
6 +12V Amplifier 12 RC - GND 18 AF - GND
19 Line In - L 1,2V/10K
20 Line In - R 1,2V/10K
Amplifier
Equalizer
CD-Changer
9.
