Blaupunkt IRC-S2 - Battery Saving Guidelines; Test Mode; LED Indicator Meanings; Technical Specifications

Battery Saving Guideline
The PIR Camera is wirelessly connected with the Control Panel at
all time. When the PIR Camera loses connection with the Control
Panel, it will actively search for the Control Panel, which will
consume extra power and greatly reduces battery life. In order to
avoid unnecessary power consumption, please follow the
guidelines below:
1. Ensure the Control Panel is powered on before removing the
battery insulator. Always learn in the PIR Camera immediately
after activating the battery.
2. Ensure the Control Panel is powered on and within signal
range when the PIR Camera is powered on.
3. When you removed the PIR Camera from the Control Panel,
make sure to remove the batteries from the PIR Camera too.
T
T
e
e
s
s
t
t
M
M
o
o
d
d
e
e
The test mode function allows you to check the PIR camera’s
detection range. Press and hold the Learn button over 3 seconds,
then release the button to enter the Test mode for 5 minutes.
The PIR Camera will first warm up for 30 seconds, do not trigger
the PIR camera during this warm up period. After the warm up is
complete, you could trigger PIR camera to check its detection
range. If PIR camera is triggered, the Blue LED will light up to
indicate.
For signal range test, please refer to the control panel manual.
L
L
E
E
D
D
I
I
n
n
d
d
i
i
c
c
a
a
t
t
o
o
r
r
Off
Normal Operation
On (2 seconds)
Movement detection under low battery,
tamper triggered condition, or Test mode.
On (30 seconds)
PIR Camera is warming up under low
battery or tamper triggered condition
Flash Rapidly
PIR Camera is transferring image under
low battery or tamper triggered condition.
Flash Once
PIR Camera sends a learn code
Flash Twice
PIR Camera is learnt into Control Panel
Flash every 20
minutes
PIR Camera has lost signal connection
with the Control Panel.
E
E
n
n
v
v
i
i
r
r
o
o
n
n
m
m
e
e
n
n
t
t
a
a
l
l
C
C
o
o
n
n
d
d
i
i
t
t
i
i
o
o
n
n
-10°C to 40°C, relative humidity 85% non-condensing.
R
R
a
a
d
d
i
i
o
o
2.4 GHz
S
S
p
p
e
e
c
c
i
i
f
f
i
i
c
c
a
a
t
t
i
i
o
o
n
n
