6
ACCESS POINT AND WIFI NETWORK SETTINGS
Go to "Connect to WiFi network" section, where you can connect the device to
the WiFi home network to be able to connect to it via it or from anyplace in the
world. To do this, select the network name from the list and press "Connect".
If required, enter the WiFi network password. When connecting the device to
the home network, the phone / tablet may be disconnected from the device's
network.
After completing the WiFi network conguration, you can disconnect from
the device network and connect the phone / tablet directly to your home WiFi
network. Control from the wBox application will work in the same way as
when the phone / tablet is connected to the device's network. If as a user you
leave the local network, eg leaving your home or enclosing mobile data, the
wBox application will signal this status as "Remote mode". In this case, you will
have access to the device data, but for security reasons settings options will
not be available.
In the "Access point settings" section, you can change the name and give the
password of the WiFi network emitted by the device. Remember that
changing the network name or password can cause disconnection with the
device immediately after clicking the "Save" button, so you should reconnect
to the WiFi network.
ADDITIONAL INFORMATION
SOFTWARE UPDATE
LOCATION AND TIME OF THE DEVICE,
SCHEDULE
To update the software in the controller, connect it to your home WiFi network
(see "Access Point and WiFi settings" section) which is connected to the
Internet. Go to “Settings” (icon at the top-right corner of the screen) and click
the "Get new rmware" button in the nal section on settings. Wait about
1 minute, do not close the interface and don’t perform other actions. The
device will download the latest software. The software version number,
hardware version and device identier can be read at the bottom of the
settings screen.
To be able to use historical air quality data, it is necessary to set the clock and
location of the device. Go to the "Device time" section of the settings and then
click "Change zone". Select your region and locations from the list, conrming
your selection with the "Save" button. The device will synchronize its time with
the time server (if the controller is in a WiFi network with Internet access) or it
will download time from the phone/tablet.
Next, in the "Device location" section, click "Set locations". The application/
browser will ask whether to share locations - allow. In the "Coordinates" eld,
the approximate coordinates of your location should appear. If the "Set
locations" button blinks red with the word "error" or the "Coordinates" eld
did not change the value from "Not set" to numeric data, a failure occurred in
the location download. You should then make sure that the phone / tablet has
a GPS module and that the location sharing support is enabled on the phone.
high quality ABS plastic
5V by microUSB connector
from -20°C to 50°C
wired, waterproof, cable length 1m
< 1W
from -55°C to 125°C
± 0,5°C in the range of -10°C to 85°C
IP32
TECHNICAL SPECIFICATIONS
bi-directional, encrypted
2.4 GHz
μWiFi, compatible with WiFi, 802.11g
31 x 45 x 15 mm
mode
compatible
devices and systems
power supply
controller
operating temperature
housing
type of probe
energy consumption
measurement range
measurement accuracy
protection level
communication standard
dimensions
for more information
visit our website
www.blebox.eu
or send us an email to:
info@blebox.eu
support is available at
support@blebox.eu
direct connection (as Access Point),
Wi-Fi connection via a standard
router, connection with access from
any location in the world (requires
only access to the Internet)
Apple iPhone, Apple iPad, iPad
Mini, Android, computers and
mobile devices supporting HTML5
transmission type
radio frequency
