Blitz HydroLift Series - Page 138

HydroLift
Technical Annex
126746 135
Electrical components HydroLift S3 6.2 t / 7.5 t and S2.2 t
Pos.
Name
HydroLift S3 6.2
t
HydroLift S3 7.5
t
HydroLift S2 8.2
t
1
Power supply 24V DC
P3576Y
P3576Y
P3576Y
2
Housing power supply
M130226Y
M130226Y
M130226Y
3
String Pot Assembly
M110187Y
M110187Y
M110187Y
4
Solenoid valve
M130017
M130017
M130017
5
Locking bracket
M120067Y
M120067Y
M120067Y
6
Battery holder
M130032
M130032
M130032
7
Battery compartment
M120167Y
M120167Y
M120167Y
8
Battery charger
118454
118454
FA966-63BK
9
Fuse 200A
FA7958‐6
FA7958‐6
FA7958‐6
10
Fuse holder
FA7958‐6
FA7958‐6
FA7958‐5
11
Hexagonal bolt
120765
120765
120765
12
Hexagonal nut
700090
700090
700090
13
Hexagonal nut
109979
109979
109979
14
Mounting plate for potentiometer
M120072Y
M120072Y
M120072Y
15
Bolt for solenoid short
N621‐9Y
N621‐9Y
N621‐9Y
16
Snap ring
120766
120766
120766
17
Bolt for solenoid long
N621‐8Y
N621‐8Y
N621‐8Y
18
Hexagonal bolt
700206
700206
700206
19
Distance sleeve
120767
120767
120767
20
Spring washer
120770
120770
120770
21
Battery 12V
117997
117997
117997
22
Internal connection cable with
socket
M130115
M130115
M130115
