COMPONENT IDENTIFICATION
6-2
24. M ć Convection motor. 1/2 hp , 208V / 115V
convection motor. Has an internal selfĆresetĆ
ting thermal overload at 250_F.
25. Meat Probe (no designation) ć J" type therĆ
mocouple meat probe which plugs into front of
the oven.
26. Meat Probe Controller (optional) ć shuts off
the oven and sounds the buzzer when set temĆ
perature has been reached.
27. (ELECTRIC OVENS) - Noise Filter ć noise filĆ
ter in control circuit.
28. Pump - pump used for removing water from
the steam generator when deliming and when
selfĆflushing.
29. (GAS OVENS) - PV , PV1 , PV2 ć pilot valves.
PV is the pilot valve on the main combination
valve used for steam. PV1 is the single coil pilot
valve used for hot air. PV2 is the pilot valve on the
main combination gas valve used for hot air.
30. P4 ć Quench snapĆdisk. SnapĆdisk located
near the rear of the drain pipe to supply power
to the quench solenoid. Closes at 167_F or
75_C. Opens at 140_F or 60_C.
31. P5 ć Temperature Control Board. Power in is
on terminals C & L1. Terminals COM & NO
close until desired set temperature is reached
in all modes of operation.
32. P11 ć Flush Disable snapĆdisk. SnapĆdisk loĆ
cated on the steam generator used to energize
the T4 Flush Solid State Timer. Closes at 160_F
or 71_C. Opens at 180_F or 82_C.
33. (ELECTRIC OVENS) - P12 ć Cold Plate Water
Flow Snap Disk snap disk located on the Solid
State Relay Cold Plate assembly, opens at
95_F or 35_C.Closes at 122_F or 50_C. ProĆ
vides normal cooling of cold plate assembly.
34. (ELECTRIC OVENS) - P13 ć Cold Plate NO
water FailĆsafe Snap Disk snap disk located on
the Solid State Relay Cold Plate assembly,
opens at 176_F or 80_ C and shuts down the
oven / closes at 149_F or 65_C.
35. (GAS OVENS) - Quench - Cold water drain
quench solenoid. Coil resistance is approxiĆ
mately 1830 ohms.
36. (ELECTRIC OVENS) - Quench - Cold water
drain quench solenoid. Coil resistance is
approximately 1830 ohms. Water supply also
for the SSR cold plate assembly.
37. Resister (designated as 5.6Ka") - Resister in
series with the buzzer to drop voltage to the
buzzer to allow for long periods of operation.
38. R5 ć Meat probe relay
D Coil is terminals 1 & 5. Coil is energized by
the meat probe control terminal 6.
D Coil energized. Terminals 4 to 3 close, enĆ
ergizing the buzzer.
D Coil not energized. Terminals 4 to 2 closed,
power to timer, S5, terminal 4.
39. (ELECTRIC OVENS) - R200 ć Hot Air Relay
coil is terminals 13 & 14 / coil is energiized
when oven is in Hot Air" or Combi" and P5
thermostat is calling for heat. Terminals 10 to
6 close, energizing K2ĆB.
40. (ELECTRIC OVENS) - R201 ć Load Splitting
Relay
D Coil is terminals 13 &14. Coil is energized
by R204 terminal 1 when steamgenerator
is full
D Coil energized. Terminals 9 to 5 close,
power is supplied to F6, then the steam
contactors. Terminals 10 to 2 open, no
power to K2ĆA Hot Air contactor.
D coil not energized. Terminals 9 to 5 are
open, no power to F6 (no power to steam
contactors). Terminals 10 to 2 are closed,
supplies power to K2ĆA Hot Air contactor.
41. (GAS OVENS) - R202 ć On demand steam
relay
D Coil is terminals 13 & 14. Coil is energized
by One shot Steam timer, T3 terminal 2.
D Coil energized terminals 9 to 5 close. This
byĆpasses the temperature thermostat
and provides power to F6 Boiler High Limit
thermostat.
D Coil not energized terminals 9 to 1 closed,
normal operation, provides power to F6
Boiler High limit thermostat.
