BC14E
9-3
STACKING
WARNING!!
Stacking should be performed by qualiĆ
fied installation personnel only. The apĆ
pliances are heavy. Take care to use propĆ
er tools and techniques when lifting and
stacking appliances.
1. Remove the drip pan from the top appliance.
2. Attach the legs or casters to the bottom apĆ
pliance.
3. Place the top appliance on the bottom apĆ
pliance. Be sure all four sides are flush.
4. Bolt the two appliances together using the
bolts provided.
5. Replace the drip pan.
6. Connect the drain, electrical and water. Refer
to page 9-4.
Drip Pan
BC14G Shown
FIGURE 2
To Next Page
