PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G
FIGURE 1
ITEM Part # DESCRIPTION SC-7G SC-10G
1. 40543 Hinge Rod 1
40544 Hinge Rod 1
2. 42137 Door Switch 1 2
42285 Switch Actuator 2 2
3. 41631 Striker 2 2
41632 Washer 2 2
40112 Lock Washer 2 2
40112 Hex Nut 2 2
42322 Washer 2 2
4. 40945 Pilot Light - Green 2 2
5. 40945 Pilot Light - Green 2 2
6. 40950 Pilot Light - Red 2 2
** 7. 42456 Dial - 60 Minutes 2 2
42456 Dial - 120 Minutes, Optional 2 2
8. 43174 Power Switch 2 2
9. 42455 Control Decal 1
42895 Control Decal 1
10. 41190 Component Mounting Board 2 2
** 11. 42452 Level Control 10K OHM 2 2
41063 Level Control 1M OHM, Optional 4 4
12. 40707 End Section 1 1
13. 40708 Terminal Block 2 2
14. 40840 Ground Lug 1 1
15. 40441 Elbow 1/4c x 1/8 MPT 2 2
16. 41036 Solenoid Valve 4 4
17. 40443 Elbow 3/8c x 1/8 MPT 4 4
