PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G
ITEM
Part # DESCRIPTION SC-7G SC-10G
39. 43276 Plug 3/4 2 2
40. 43277 Tee 3/4 2 2
41. 41044 Down Tube 2 2
42. 43278 Close Nipple 3/4 2 2
43. 41078 Relief Valve 5 psi 2 2
44. 43279 Nipple 3/4 x 2 ½ 2 2
45. 43280 Elbow 3/4 2 2
* 46. 40369 Steam Diverter 4 4
* 47. 40205 Thermostat Fitting 3/8 C x 3/8 MPT 2 2
* 48. 40475 Water Connection 3/8 C 2 2
* 49. 40411 Elbow - ½ C Tank Left Hand 2 2
* 50. 40199 Pan Rack - Top 2
40200 Pan Rack - Bottom 2
40201 Pan Rack 4
* 51. 41633 Perforated Door Trough 1 1
* 52. 41195 Right Hand Side Panel 1
41188 Right Hand Side Panel 1
* 53. 41196 Left Hand Side Panel 1
41189 Left Hand Side Panel 1
* 54. 40794 Top Cover 1 1
55. 43287 Bottom Flue 1 1
43288 Top Flue 1 1
* 56. 43281 Flue Assembly 1 1
* 57. 41194 Right Hand Side Riser 1 1
* 58. 41193 Left Hand Side Riser 1 1
* 59. 41191 Front Side Riser 1
1
* 60. 41210 Rear Side Riser 1 1
To Next Page
