Blodgett SC-10G - Page 9

PARTS LIST, GAS CONVECTION STEAMER, MODELS SC-7G, SC-10G
BURNER PARTS, NATURAL GAS ONLY FIGURE 3
ITEM Part # DESCRIPTION SC-7G SC-10G
1. 41035 Spark Electrode 2 2
2. 41033 Spark Electrode Bracket 2 2
3. 41184 Gas Manifold Assembly 2 2
4. 40386 Orifice #43 4 4
5. 41813 Plug 1/8 NPT 2 2
6. 41185 Burner Mounting Bracket 2 2
7. 41183 Burner 4 4
8. 41056 Burner Support 2 2
9. 40270 Fender Washer 1/4 4 4
10. 43015 Hex Cap Screw 1/4-20 x 1 ½ 2 2
11. 43005 Machine Screw 10-32 x 3/8 4 4
12. 43013 Machine Screw 1/4-20 x ½ 2 2
43284 Lock Washer 1/4 2 2
13. 43285 Machine Screw 8-32 x 3/8 8 8
14. 43006 Machine Screw 6-32 x 3/8 2 2
