Blooma Moses - Assembly Step 01; Initial Assembly of Base Components

01
Assembly Assemblage Montaż
Сборка Asamblare Montaje
Montagem Montaj
[08]
[14]
[12] x 5
[13] x 5
[14] x 4 [15] x 47 [16] x 8 [18] x 11
(M8)
[15][21][19]
x 4
[08] x 4
[14] x 4
[15] x 8
[19] x 8
[21] x 8
[27] x 1
[17] x 6
[19] x 47
(M6)
[20] x 11
(M6 x 18 mm)
[21] x 22
(M6 x 15 mm)
[22] x 3
(M6 x 32 mm)
[23] x 24
(M6 x 62 mm)
[24] x 1 [25] x 15
(ST4.2 x 13 mm)
[26] x 16 [27] x 2 [28] x 1
