SERVICE@BLUDOT.COM | 2ASSEMBLY NOTES
PT. 1038 x 2
PT. 1038 x 6
PT. 9004 x 1
PT. 9004 x 1
Top view
Top view
Step 02
ATTACH REMAINING LEGS.
Finish attaching legs as shown using the
hardware provided. Tighten bolts after all legs
are attached.
Step 01
ATTACH LEGS.
Begin attaching legs as shown using the
hardware provided. Do not fully tighten the
bolts until after Step 02.
To Next Page
