Blue Sea Systems 8413 - Page 4

Page 4 of 4
980037800 Rev.001
4600 Ryzex Way Bellingham, WA 98226 p: 360.738-8230 f: 360.734-4195
Panel Wiring Schematic AC/DC Power Distribution Panel 8413
A
USB
B
C
M5
FROM DC
POSITIVE
TO DC GROUNDING SYSTEM
TO DC
NEGATIVE
TO DC
GROUNDING
SYSTEM
CONNECT TO
(-) DC NEGATIVE
CONNECT TO
DEVICE HOT
CONNECT TO
DEVICE HOT
CONNECT TO
DEVICE HOT
CONNECT TO
DEVICE HOT
CONNECT TO
DEVICE HOT
120V AC
SOURCE
CONNECT TO
(+) DC LOAD
CONNECT TO
(+) DC LOAD
CONNECT TO
(+) DC LOAD
CONNECT TO
(+) DC LOAD
CONNECT TO
(+) DC LOAD
CONNECT TO
(+) DC LOAD
FROM AC
SAFETY
GROUND
FROM AC
NEUTRAL
FROM AC HOT
CONNECT TO
(-) DC NEGATIVE
CONNECT TO
(+) DC POSITIVE FEED
SHUNT
CONNECT TO
(+) DC LOAD
CONNECT TO
(+) DC LOAD
100A DC MAIN
15A 15A 15A 15A 15A 15A
15A 15A
15A 15A 15A 15A 15A
H
30A
N
30A
LED LED LED LED LED LED LED LED
LED LED
LED LED
LED LED LED LED LED LED LED LED LED
DC
POSITIVE
BUS
DC
BACKLIGHT
BOARD
DC
BACKLIGHT
BOARD
DC
GROUND
BUS
DC
NEGATIVE
BUS
AC
SAFETY
GROUND
BUS
AC
NEUTRAL
BUS
DC
GROUND
BUS
DC
NEGATIVE
BUS
DC
POSITIVE
BUS
AC
HOT
BUS
FROM
DEVICE
NEUTRAL
FROM
DEVICE
SAFETY
GROUND
FUSE
1.0A TO
2.0A
DC
BACKLIGHT
BOARD
LED LED LED
