INTRODUCTION
The Q360 In-Floor Cleaning system is designed to give years of service. The benefits of
deep circulation are well documented and scientifically proven to give the most
efficient swimming pool circulation available. This superior circulation delivers substantial
chemical, electrical and heat savings to the pool owner while offering outstanding
cleaning benefits as well.
The unique engineering of the Q360 System smoothly transfers power from the turbine to
the ports or outlets with minimal friction loss and back pressure, allowing the maximum
possible flow rate to the in-floor cleaning jets. The open gear design allows for effective
pass-through of debris, greatly minimizing annoying cleaning system disruptions and
lowering maintenance costs even further over other in-floor systems.
The Innovative pressure-safe valve design protects your system by ensuring that one port
is always open. Large 2" inlet and (6) 2" ports maximize flow rate. Reinforced space-age
molded construction weathers the elements and is saltwater/chemical friendly. See-
through lid design allows for inspection of turbine and gears without the need for
disassembly.
Failure to follow recommended installation methods could void warranties and cause
injury.
COMPONENTS
The Q360 High Performance Water Valve: The Q360 Jet Complete:
A. Valve Housing or Body A. Jet (High Flow & Low Flow)
A. Cassette B. Collar
B. Turbine C. Protective Cap
B. Clear Lid
C. O-Ring
D. Band Clamp w/ nut
