10. PARTS LIST & DIAGRAM (CONTINUED)
# Part Description QTY. MFG No. BW No. For Model #
1
ELBOW CONNECTOR 1 AF2501 NEP4166 NBP6170 & NBP6195
WITH O-RING 1 1 AF2502 NEP4167 NBP6170 & NBP6195
2
AIR VENT PLUG 1 AF2503 NEP4168 NBP6170 & NBP6195
WITH O-RING 2 1 AF2504 NEP4169 NBP6170 & NBP6195
3
CLEAR TANK COVER 1 AF2505 NEP4170 NBP6170 & NBP6195
4
UPPER WATER DISTRIBUTOR 1 AF2506 NEP4171 NBP6170 & NBP6195
5
CLAMP BOLT 1 3013 NEP4070 NBP6170 & NBP6195
CLAMP BOLT NUT & WASHER 1 3014 NEP4071 NBP6170 & NBP6195
CLAMP PIN 1 3015 NEP4072 NBP6170 & NBP6195
RIGHT CLAMP HALF 1 3016 NEP4073 NBP6170 & NBP6195
LEFT CLAMP HALF 1 3017 NEP4074 NBP6170 & NBP6195
6
1.25”-1.5” (32/38MM) HOSE FITTING 1 AF2513 NEP4172 NBP6170 & NBP6195
HOSE FITTING GASKET 1 AF2514 NEP4173 NBP6170 & NBP6195
7
TANK PLUMBING ADAPTOR 1 AF2515 NEP4174 NBP6170 & NBP6195
8
TANK PLUMBING ADAPTOR GASKET 2 AF2516 NEP4175 NBP6170 & NBP6195
9
INTERNAL PLUMBING “L” TUBE 1 AF2517 NEP4176 NBP6170 & NBP6195
10
AIR RELIEF PIPE 1 AF2518 NEP4177 NBP6170 & NBP6195
11
TANK COVER O-RING 1 AF2519 NEP4178 NBP6170 & NBP6195
12
BLOW MOULDED TANK 1 AF2520 NEP4179 NBP6170 & NBP6195
13
PUMP TO TANK LID HOSE 1 AF2521 NEP4180 NBP6170 & NBP6195
14
1/3HP WATER PUMP 1 AF2522 NEP4268 NBP6170 & NBP6195
15
BASE PLATE 1 AF2523 NEP4058 NBP6170 & NBP6195
16
SCREW KIT 2
AF2524 NEP4261 NBP6170 & NBP6195
17
HOSE CLAMP 2 AF2525 NEP4069 NBP6170 & NBP6195
18A
18B
WATER RETURN FITTING KIT (1.25”) 1 91194 NBP6160 NBP6170
WATER RETURN FITTING KIT (1.25”/1.5”) 1 90594 NBP6196 NBP6195
19
WATER INTAKE FITTING KIT (1.25”/1.5”) 1 91195 NBP6159 NBP6170 & NBP6195
20
FILTER MEDIA COTTONTAIL
TM
BALLS 20 Aqualoon ATX NE4509 NBP6170 & NBP6195
PARTS LIST - EASY CLEAN 200 FILTER SYSTEM
