ASSEMBLY INSTRUCTIONS (CONT.)
4. Carbon Heater Models Only: Attach the FLOOR HEATER to the FLOOR with 1-1/2” SCREWS.
Connect the heater plug.
5. Slide the BENCH HEATER PANEL into place between the LEFT and RIGHT PANELS. Connect
the heater plug. Note: For Carbon Heater Models, make sure the FLOOR HEATER cable is placed
through the groove in the bottom of the BENCH HEATER PANEL.
6. Attach BENCH SEAT with 2” SCREWS.
6
