BlueWear 002104 - Description; Component Identification; Adjustment; Fitting and Adjustment Guide

EN
20
USE
BATTERY
Rechargeable battery
1. Make sure the power switch is in the OFF
position by turning the volume control
anticlockwise all the way.
2. Charge the rechargeable battery with the
micro USB cable.
Optional battery power
1. Make sure the power switch is in the OFF
position by turning the volume control
anticlockwise all the way.
2. To disconnect the power to the 3 x AAA
batteries, open the battery ap and
remove the rechargeable battery by
carefully pulling loose the connection.
3. Insert 3 x AAA batteries.
4. Close the battery ap.
SETTING THE TIME
1. Make sure the power switch is in the OFF
position by turning the volume control
anticlockwise all the way.
2. Press the up or down arrow to switch
between 12 and 24 hour mode.
3. Press MODE. When the time ashes, press
the up or down arrow to set the hour.
Press MODE to conrm. Set the minutes in
the same way and press MODE to conrm.
RADIO
10 radio stations in the AM band and 10 in the
FM band can be preset.
1. Make sure the power switch is in the ON
NB 1974
PZT GmbH, An der Junkerei48F,
D-26389Wilhelmshaven, Germany
DESCRIPTION
FIG. 1
1. Antenna
2. 2. Down arrow
3. 3. Up arrow
4. 4. Display
5. 5. MODE
6. 6. BT(Bluetooth)/Band
7. 7. AUX input
8. 8. Volume control/power switch
9. 9. Microphone
10. 10. Micro USB port for charging
ADJUSTMENT
1. Put the yoke over your head and adjust
both cups so that they cover the ears.
Place the cup with the control over the
right ear. The cups only provide adequate
ear protection if the yoke lies over the
head.
2. Move the cups up or down in the yoke to
adjust them to t rmly and comfortably.
3. Check that the sealing rings in the cups
t rmly against the head, without
intermediate objects such as pens or
sidepieces. Make sure that as little hair as
possible comes under the cups.
4. Enlarge the cups just enough so that they
do not press on the ears. Never attempt to
change the shape of the yoke.
