24
EN
OPERATION
To light heater
1. Fit battery type AAA provided into ignition button (“+“ side up). Remove
battery during periods of non-use to prevent battery leak.
2. Turn on the gas by turning the gas regulator to the on position.
3. Press the enabling button and hold it down for about 10 seconds. Hold
the enabling buttion down and at the same time press the ignition button
to light the ame. With the ame lit, keep holding the enabling button
down for a further 15 seconds,then release.
4. If there is no spark, check the battery type AAA is correctly tted. (The
pilot ame can be viewed at the middle of the coal bed).
5. Turn the thermostat dial to the high position 6 (see gure D).
counterclockwise to the + position, i.e., to the maximum output.
6. When the room has reached a comfortable temperature,turn the
thermostat slowly to the low position until the burner reaches the
minimum height of the ame and it is not exceeded.
7. Thus, the device will automatically maintain the temperature set,
alternating between the maximum output and the minimum output, and
vice versa. Reference temperature for each position
1 18/19°C 4 29/30°C
2 23/24°C 5 31/32°C
3 26/27°C 6 33/34°C
The above temperature range is just for refence,not exact.
Enabling button
Thermostat
Piezoelectric button
