Blyss JELBI - Page 39

41
EAN: 3663602632177 / 3663602632184
(M2733DJ / M2733DJM)
EAN: 3663602632191 (P419J)
4B
Blue
Green
Orange
Blue
Green
Orange
(M2733DJ / M2733DJM)
P419J
EAN: 3663602632191
2. Power
2. Power
2. Lock
4. Gate Opener
6. 2 wires 0~25 m, min. 0.75 mm²
6. 2 wires 25~100 m, min. 1.5 mm²
5. Maximum distance between indoor
unit and outdoor unit: 100 m
6. 2 wires 0~25 m, min. 0.75 mm²
3663602632191-Blyss-IM-V04.indb 41 12/2/2019 3:50 PM
2
1
4
3
2
1
4
3
2
1
2
1
