Description of your controller’s symbols:
There are a number of technical markings on your controller. These can be explained as
follows:
The product is manufactured in China for Bio-Medical Research Ltd,
Parkmore Business Park West, Galway, Ireland.
The controller requires 1 x 3.6 volt (NiMH) DC battery pack. DC is indicated by the
symbol:
The Output Frequency indicates the number of pulses per second transmitted by the
controller. This is measured in hertz, which is indicated by “Hz”.
Output (RMSA) means the maximum output root mean square current for each channel.
Output (RMSV) means the maximum output root mean square voltage for each channel.
This symbol means “Attention, consult the accompanying documents”.
This symbol means type BF applied parts (GelPads).
SN stands for ‘serial number’. On the label on the back of the controller is the serial
number specific to this product. The letter preceding the number indicates the year of
manufacture, where “V” denotes 2016, “W” denotes 2017 etc.
The garment’s batch number is represented on the garment packaging, by the number
corresponding with the LOT symbol.
At the end of the product lifecycle, do not throw this product or batteries into the
normal household garbage, but bring it to a collection point for the recycling of
electronic equipment.
Rated Outputs – Voltage/Currents: X:60
Parameter 500! 1K! 1K5!
Output RMSV 3.8V 7V 7.9V
Output RMSA 7.7mA 7mA 5.3mA
Output Frequency 50Hz 50Hz 50-Hz
DC Component: Approx. 0 C 0 C 0 C
Positive Pulse Width: 100-125µs 100-125µs 100-125µs
Negative Pulse Width: 100-125µs 100-125µs 100-125µs
Interphase Interval: 100 µs 100 µs 100 µs
Garment Materials:
Outer Material: 100% Nylon
Inner Material: 100% Polyester laminated to 100% polyurethane
Binding: 100% Polyester
Hook & Loop: 100% Nylon
Foam: EVA
Elasticated Straps: 85%Nylon, 15% Spandex
