BMT 802 GTX - Page 14

www.bmt-team.com
BAG 01
Pag. 12
INSTRUCTION MANUAL
GTX
MA 4x4
LOCTITE
MA 3x8
LOCTITE
A
x2
L
L
R R
LOCTITE
LOCTITE
MA 3x6
MA 3x10
MA 3x10
MA 3x16
3,00 mm.
4,50 mm.
Front
Rear
BMT.0455
BMT.0453
BMT.0363
BMT.1091
BMT.0901
BMT.0033 BMT.1092
BMT.0150
BMT.0106
BMT.1100
PA8435
PA0197
PA0197
BMT.1100
BMT.0017
