Electronic displays
Overview, instrument cluster
1 Messages, e.g. Check Control 75
Time 78
2 Range 78
3 Computer 82
4 Navigation display, see user's manual for
Navigation, Entertainment and Communi‐
cation.
Service requirements 79
Miles/trip miles 78
5 Selection list, e.g., radio 82
Current fuel consumption 79
Energy recovery 79
External temperature 78
Transmission display 70
Multifunctional instrument
display
The concept
The instrument dispaly is a variable display.
When the driving mode is changed, the ap‐
pearance is changed to reflect the new driving
mode. The change of appearance can be de‐
activated in the Control Display.
Some of the displays in the instrument display
may differ from the way they are shown in this
owner's manual.
Seite 72
Controls Displays
72
Online Edition for Part no. 0140 2 910 771 - VI/13
