Heating and ventilation/Air conditioning*
1 Air flow toward the windshield and
side windows
2 Air flow toward upper body
The rotary dials allow infinitely-vari-
able regulation of the air supply. You
can change the airflow direction with
the lever in the center of the vent or
by rotating the vent grille 87
3 Front footwell ventilation
4 Air distribution onto the
> windows
> upper body
> footwell
All intermediate positions are
possible 86
5 Temperature 86
6 Air supply
The heating and ventilation are oper-
ational beginning with position 1 86
7 Air conditioning 86
8 Recirculated air mode 86
