17
1 Fuel gauge 77
2 Turn signal indicators 20
3 Speedometer
4 Indicator and warning
lamps 18 to 21
5 Tachometer and engine oil temper-
ature gauge 76
6 Engine coolant temperature
gauge 77
7 Indicator and warning
lamps 18 to 21
8 Control button for
>
Clock 79
>
Unit of measure of outside tem-
perature display 80
9 Display for sequential M gearbox
with Drivelogic 68
10 Indicator lamp for Dynamic Stability
Control (DSC) 83
11 Display for
>
Trip odometer/Odometer 76
>
Clock 79
>
Service interval 78
>
Computer 80
12 Check Control 78
13 Trip odometer, reset to zero 76
14 Indicator and warning
lamps 18 to 21
Instrument cluster
