Instrument cluster
1 Fuel gauge with indicator lamp
for fuel reserve 70
2 Indicator lamp for turn signals 22
3 Speedometer
4 Indicator lamp for high beams 22
5 Tachometer and engine oil
temperature gauge 70
6 Engine coolant temperature
gauge 71
7 Indicator and warning lamps
(clockwise) for
>
Parking brake 21
>
Brake hydraulic system/Dynamic
Brake Control (DBC) 20, 21
>
Antilock Brake System (ABS) 21
>
Airbags 21
>
Please fasten safety belts 21
>
Cruise control
*
22
8 CHECK button 72
9 Outside temperature display 69
10 Indicator lamp for Dynamic Stability
Control (DSC) 21
11 Trip odometer 69
12 Indicator for
>
Check Control 72
>
Onboard computer: refer to the
Radio Owner's Manual
>
Radio and cellular telephone:
refer to the separate Owner's
Manual
13 Odometer 69
14 Service Interval Display 71
15 Trip odometer, reset to zero 69
16 Indicator and warning lamps
(clockwise) for
>
Fog lamps 22
>
Battery charge current 20
>
Engine oil pressure 20
>
CHECK ENGINE lamp 21
You can display the outside tem-
perature and distance driven in
different units of measurement.
<
