Automatic climate control
1 To defrost windows and remove condensa‐
tion
2 Temperature, left
3 AUTO program
4 To switch off the system
5 Air flow, AUTO intensity
6 Display
7 SYNC program
8 Maximum cooling
9 Temperature, right
10 Air conditioning
11 Automatic recirculated-air control/recircu‐
lated-air mode
12 Seat heating, right 84
13 Air distribution settings
14 Seat heating, left 84
15 Interior temperature sensor
16 Rear window defroster
Climate control functions in
detail
Switching the system on/off
Switching on
Press any button except for the following:
▷ SYNC program.
▷ Rear window defroster.
▷ Seat heating.
Switching off
Press the button.
Temperature
Concept
The automatic climate control achieves the set
temperature as quickly as possible, if necessary
by using the maximum cooling or heating power,
and then keeps it constant.
Seite 194
CONTROLS
Climate control
194
