Convertible top switch
Opening
Push the switch and hold it.
The windows roll down and the convertible top
opens while the switch is being pushed.
Closing
Pull the switch and hold it.
The windows are lowered, the convertible top is
closed, and the windows are raised again while
the switch is being pulled.
Displays and control
elements
In the vicinity of the steering
wheel
1 Light switch element
2 Turn signal indicator, high beams
3 Instrument cluster
4 Wipers
Indicator/warning lights
Instrument cluster
The indicator/warning lights can light up in a vari‐
ety of combinations and colors.
Several of the lights are checked for proper func‐
tioning and light up temporarily when the engine
is started or standby state is switched on.
Driver's door
1 Central locking system
2 Seats, comfort features
3 Power windows
4 Exterior mirrors
5 Unlocking the trunk lid
Switch console
1 Selector lever
2 Controller
Seite 22
QUICK REFERENCE
Entering
22
Online Edition for Part no. 01402779113 - II/19
