3. Pull the cable (Fig. 39) while the second person lifts the operator guard a small
amount until the lock mechanism is released.
4. Both persons must slowly lower the operator guard by holding the bottom of the
operator guard and the grab handles (Fig. 37).
5. Install the two (2) bolt assemblies (including washers). Tighten the nuts to 40
-50 ft-Ibs. (54 - 69 Nm) torque (Fig. 36).
6. Connect the wiring harness behind the seat (Fig. 35).
-18-
Fig. 39 Operator Guard Cable
