Bobcat 743 - Page 35

o
o
o
To service the electrical system:
1. Check to see that the battery cables are clean and tight. Remove any acid of
corrosion from the battery and cables with a baking soda and water solution
(Fig. 58). Cover the terminals with Clark Battery Saver to prevent corrosion.
Install the covers on the terminals.
2. Two 25 ampere fuses are installed in the dash panel. If the fuses become
damaged, replace them with same type and size fuses.
USING AN EXTRA BATTERY (JUMP STARTING)
Lead-acid batteries produce flammable
and explosive gases. Keep arcs, sparks,
flames and lighted tobacco away from
the battery. Make a "jump" start
connection as recommended by the
manufacturer. When connecting extra
battery for "jump" start always make
the last connection (negative cable) to
the engine (never at the battery). When
removing the "jump" start cables,
always remove the negative cable from
the engine first.
If is is necessary to use an extra battery to start the engine, BE CAREFUL! This is a
two person operation. There must be one person in the operator's seat and one
person to connect and disconnect the battery cables.
Lead-acid batteries contain sulfuric acid
which will damage the eyes or skin on
contact. Always wear goggles to avoid
acid in the eyes. If acid contacts the
eyes, wash immediately with much
clean water and get medical attention.
Wear rubber gloves and protective
clothing to keep acid off the skin. If acid
contacts the skin, wash off
immediately with clean water.
1. The ignition must be in the off position.
2. The battery to be used must be of the same voltage.
3. Battery terminals have identification marks. The positive terminal is marked ( +)
a nd negative terminal is marked (-).
4. The negative terminal (-) of the battery must be connected to the engine.
DO NOT charge a frozen battery
because it can explode and cause
personal injury. Let the battery warm to
60° F. (15.5° C.) before putting on a
charger.
-27-
• ~·lDIIIa ~¥E
A-2741
Fig. 58 Cleaning Battery
