B-23185B
B-23186B
FRONT
LIGHTS
GRAB
HANDLES
OPERATOR SEAT
with SEAT BELT
AND SEAT BAR
TILT
CYLINDERS
[3] BUCKET
STEP
LIFT ARM
[2] TYRES
REAR
GRILL
BUCKET
STEPS
FRONT AUXILIARY
QUICK COUPLERS
TAIL LIGHT
REAR
DOOR
REAR
LIGHT
[4] OPERATOR CAB
(ROPS AND FOPS)
LIFT
CYLINDER
LIFT ARM
SUPPORT DEVICE
OPERATION &
MAINTENANCE
MANUAL AND
OPERATOR’S
HANDBOOK
[1] BACK-UP
ALARM
[1] Optional or Field Accessory (Not Standard Equipment)
[2] TYRES - The Bobcat loader is factory equipped with standard tyres.
[3] BUCKETS - Several different buckets and other attachments are available for the Bobcat loader.
[4] ROPS, FOPS - Roll Over Protective Structure, per ISO 3471, and Falling Object Protective Structure per ISO 3449, Level I.
Level II is available.
