160 S130 Operation & Maintenance Manual
DIAGNOSTIC SERVICE CODES (CONT'D)
Service Codes List (Cont’d)
CODE DESCRIPTION CODE DESCRIPTION
M7207 Electric fan 1 relay open circuit W3251 Lift actuator short to battery
M7304 Remote control no communication W3252 Tilt actuator short to battery
M7316 Remote control no signal from transmitter W3253 Lift handle / pedal short to earth
M7423 Main controller not programmed W3254 Tilt handle / pedal short to earth
M7472 Main controller in boot code W3255 Lift handle / pedal short to battery
M7497 Main controller software updated W3256 Tilt handle / pedal short to battery
M7504 Drive no communication W3257 Lift actuator reduced performance
M7604 Left display panel no communication W3258 Tilt actuator reduced performance
M7748 Key switch multiple W3259 Lift actuator wrong direction
M7839 Hourmeter changed W3260 Tilt actuator wrong direction
M7974 Door open W3261 Handle lock short to earth
W3262 Handle lock short to battery
W3223 ACS calibration required W3263 Pedal lock short to earth
W3224 ACS calibration failed W3264 Pedal lock short to battery
W3231 Tilt actuator fault W3265 Sensor supply voltage out of range
W3232 Tilt actuator wiring fault W3266 Battery voltage out of range
W3233 Tilt handle wiring fault W3267 Handle/pedal switch flipped while operating
W3234 Tilt actuator not in neutral W3268 Lift handle information error
W3235 Tilt handle / pedal not in neutral W3270 Right hand drive short to earth
W3236 Lift actuator fault W3271 Right hand drive short to battery
W3237 Lift actuator wiring fault W3274 Left joystick X-axis out of range
W3238 Lift handle wiring fault W3275 Interrupted unswitched power
W3239 Lift actuator not in neutral W3276 CAN joystick information error
W3240 Lift handle / pedal not in neutral W3277 Remote control information error
W3241 No communication W3905 Left joystick X-axis not in neutral
W3249 Lift actuator short to earth W4005 Right joystick X-axis not in neutral
W3250 Tilt actuator short to earth W4007 Right joystick Y-axis not in neutral
