36 S130 Operation & Maintenance Manual
INSTRUMENT PANEL IDENTIFICATION (CONT’D)
Left Panel (Cont’d)
* See SYSTEM SETUP & ANALYSIS for Service Code description. (See DIAGNOSTIC SERVICE CODES on Page
155.)
REF.
NO.
DESCRIPTION FUNCTION / OPERATION
20 INFORMATION Cycles through (after each button press):
• Hourmeter (On start up)
• Engine rpm
• Battery voltage
• Service codes*
21 TRACTION LOCK OVERRIDE Functions only when the seat bar is raised and the engine is running. Press
once to unlock the brakes. Allows you to use the steering levers or joystick(s)
to move the loader forward or backward when using the backhoe attachment.
(See TRACTION LOCK OVERRIDE in this manual.) Press a second time to
lock the brakes.
22 PRESS TO OPERATE LOADER Press to activate the BICS™ when the seat bar is down and operator is
seated in operating position. Button will light.
Press and hold three seconds to engage Drive Response and Steering Drift
Compensation. (See DRIVE RESPONSE and STEERING DRIFT
COMPENSATION in this manual.)
23 ALARM The alarm beeps when Error, Warning or Shutdown conditions exist.
