S250 Bobcat Loader
SPEC-7 Operation & Maintenance Manual
LOADER SPECIFICATIONS (S250) (CONT’D)
Fluid Specifications
Environmental
Engine coolant Polypropylene glycol/water mix (53% – 47%) with freeze protection to
-37°C
Engine oil Oil must meet API Service Classification of CD, CE, CF4, CG4, or better.
Recommended SAE viscosity number for anticipated temperature range.
* Can by used only when available with appropriate diesel rating.
For synthetic oil use the recommendation from the oil manufacturer.
Hydraulic fluid Bobcat Fluid (P/N 6563328). If fluid is not available use 10W-30/10W
Class SE motor oil for temperatures above -18°C or 5W-30 Class SE
motor oil for temperatures below -18°C.
Noise level L
pA
(EU Directive 2000/14/EC) 85 dB(A)
Noise level L
WA
(EU Directive 2000/14/EC) 104 dB(A)
Whole body vibration (ISO 2631–1)
1.19 ms
-2
Hand-arm vibration (ISO 5349–1)
2.67 ms
-2
