Bobcat S450 - Levelling The Ground Using Float (Foot Pedals)

116 S450 Operation & Maintenance Manual
OPERATING PROCEDURE (CONT’D)
Operating With A Full Bucket
Figure 139
Figure 140
With a full bucket, go up or down the slope with the heavy
end toward the top of the slope [Figure 139] and
[Figure 140].
Raise the bucket only high enough to avoid obstructions
on rough ground.
Operating With An Empty Bucket
Figure 141
Figure 142
With an empty bucket, go up or down the slope with the
heavy end toward the top of the slope [Figure 141] and
[Figure 142].
Raise the bucket only high enough to avoid obstructions
on rough ground.
NA1142
With Bucket Full
Going Up Slope
NA1143
With Bucket Full
Going Down Slope
NA1134
With Bucket Empty
Going Up Slope
NA1135
With Bucket Empty
Going Down Slope
