178 S450 Operation & Maintenance Manual
HYDRAULIC / HYDROSTATIC SYSTEM (CONT’D)
Removing And Replacing Hydraulic Fluid (Cont’d)
Earlier Models
Figure 248
Remove the clamp (Item 1). Pinch off the hose (Item 2)
[Figure 248] near the fitting and disconnect hose from
the fitting.
Skip ahead to All Models. (See All Models on Page 179.)
Later Models
Figure 249
Remove the left side access cover bolts (Item 1)
[Figure 249] and remove the access cover.
Figure 250
Remove the clamp (Item 1). Pinch off the hose (Item 2)
[Figure 250] near the fitting and disconnect hose from
the fitting.
Skip ahead to All Models. (See All Models on Page 179.)
