203 S450 Operation & Maintenance Manual
DIAGNOSTIC SERVICE CODES (CONT'D)
Service Codes List (Cont’d)
CODE DESCRIPTION CODE DESCRIPTION
A8703 ACD output ‘H’ error OFF D7534
Drive left front wheel angle sensor out of range
low
A8705 ACD output ‘H’ short to battery D7535
Drive right rear wheel angle sensor out of range
low
A8706 ACD output ‘H’ short to earth D7536
Drive left rear wheel angle sensor out of range
low
A8707 ACD output ‘H’ open circuit D7537 Drive 5 volt sensor supply 1 out of range low
A8802 Reversing solenoid error ON D7538 Drive 5 volt sensor supply 2 out of range low
A8803 Reversing solenoid error OFF D7539 Drive left swash plate sensor out of range high
D7540 Drive left swash plate sensor out of range low
D3905 Left joystick X-axis not in neutral D7541 Drive right swash plate sensor out of range high
D3907 Left joystick Y-axis not in neutral D7542 Drive right swash plate sensor out of range low
D4007 Right joystick Y-axis not in neutral D7543 Drive left forward drive solenoid error ON
D7501 Drive CAN joystick information error D7544 Drive left reverse drive solenoid error ON
D7504 Drive no communication from drive controller D7545 Drive right forward drive solenoid error ON
D7505 Drive left joystick X-axis not in neutral D7546 Drive right reverse drive solenoid error ON
D7507 Drive left joystick Y-axis not in neutral D7547 Drive right front steer extend short to battery
D7508 Drive right joystick Y-axis not in neutral D7548 Drive left front steer extend short to battery
D7509
Drive operating mode switch short to earth or
battery
D7549 Drive right rear steer extend short to battery
D7510 Drive improper joysticks installed D7550 Drive left rear steer extend short to battery
D7511 Drive left speed sensor not connected D7551 Drive steer pressure short to battery
D7512 Drive right speed sensor not connected D7552 Drive back-up alarm error ON
D7513 Drive right front wheel angle sensor stuck D7553 Drive left forward drive solenoid error OFF
D7514 Drive left front wheel angle sensor stuck D7554 Drive left reverse drive solenoid error OFF
D7515 Drive right rear wheel angle sensor stuck D7555 Drive right forward drive solenoid error OFF
D7516 Drive left rear wheel angle sensor stuck D7556 Drive right reverse drive solenoid error OFF
D7517 Drive left swash plate not in neutral D7557 Drive right front steer extend short to earth
D7518 Drive right swash plate not in neutral D7558 Drive right front steer retract short to earth
D7519 Drive left joystick X-axis out of range high D7559 Drive left front steer extend short to earth
D7521 Drive left joystick Y-axis out of range high D7560 Drive left front steer retract short to earth
D7522 Drive right joystick Y-axis out of range high D7561 Drive right rear steer extend short to earth
D7523
Drive right front wheel angle sensor out of range
high
D7562 Drive right rear steer retract short to earth
D7524
Drive left front wheel angle sensor out of range
high
D7563 Drive left rear steer extend short to earth
D7525
Drive right rear wheel angle sensor out of range
high
D7564 Drive left rear steer retract short to earth
D7526
Drive left rear wheel angle sensor out of range
high
D7565 Drive steer pressure short to earth
D7527 Drive left swash plate out of position D7566 Drive back-up alarm error OFF
D7528 Drive right swash plate out of position D7567 Drive no communication from Bobcat controller
D7529 Drive left joystick X-axis out of range low D7568 Drive angle sensors not calibrated
D7531 Drive left joystick Y-axis out of range low D7569 Drive battery voltage out of range high
D7532 Drive right joystick Y-axis out of range low D7570
Drive interrupted power (also occurs after
software updates)
D7533
Drive right front wheel angle sensor out of range
low
D7571 Drive battery voltage out of range low
