218 S450 Operation & Maintenance Manual
(S450) LOADER SPECIFICATIONS (CONT’D)
Performance
Engine
Rated Operating Capacity
(ISO 14397-1)
608 kg (1340 lb)
with 160 Pound Axle Weight Kit
(ISO 14397-1)
643 kg (1417 lb)
Tipping Load (ISO 14397-1) 1215 kg (2679 lb)
Operating Weight 2365 kg (5214 lb)
Breakout Force – Lift 1203 kg (2653 lb)
Breakout Force – Tilt 1224 kg (2698 lb)
Travel Speed:
– Single Speed Loader 0 – 11,4 km/h (0 – 7.1 mph)
– Two-Speed Loader (Option):
Low Range 0 – 10,5 km/h (0 – 6.5 mph)
High Range 0 – 14,8 km/h (0 – 9.2 mph)
Make / Model Kubota / V2203-M-DI-E2B Stage III A
Fuel / Cooling Diesel / Liquid
Horsepower:
– ISO 9249 EEC / SAE J1349 Net 34,3 kW (46.0 hp) @ 2800 rpm
– ISO 14396 Gross 35,9 kW (48.1 hp) @ 2800 rpm
– SAE J1995 Gross 36,4 kW (48.8 hp) @ 2800 rpm
Torque:
– ISO 9249 EEC / SAE J1349 Net 140,3 N•m (103.5 ft-lb) @ 1700 rpm
– SAE J1995 Gross 149,8 N•m (110.5 ft-lb) @ 1700 rpm
Low Idle rpm 1075 – 1225
High Idle rpm 2860 – 3000
Number of Cylinders 4
Displacement
2196 cm
3
(134.0 in
3
)
Bore / Stroke 87 mm / 92 mm (3.43 in / 3.64 in)
Lubrication Gear Pump Pressure System with Filter
Crankcase Ventilation Closed Breathing
Air Cleaner Dry replaceable paper cartridge with separate safety element
Ignition Diesel – Compression
Air Induction Naturally Aspirated
Engine Coolant Propylene Glycol / Water Mixture
Starting Aid Glow plugs automatically activated as needed in RUN position
