91 S450 Operation & Maintenance Manual
ATTACHMENT CONTROL DEVICE (ACD)
This machine may be equipped with an Attachment Control Device.
Description
Figure 88
Connect the attachment electrical harness to the
attachment control device (Item 1) [Figure 88].
Figure 89
You will need the 14-Pin Attachment Control Device kit
(Item 1) [Figure 89] to operate early model attachments.
See your Bobcat loader dealer.
Standard And ACS (If Equipped)
Figure 90
SJC (If Equipped)
Figure 91
Additional switches (Items 1, 2, and 3) [Figure 90] or
[Figure 91] are used to control some attachment
functions through the attachment control device.
See the appropriate attachment Operation &
Maintenance Manual for control details.
