BOBKONA F7615 - Chaise on the Right Assembly

PARTS LIST
A
1.
4. 5. 6.
2. 3.x12
x12 x12x1
x12 x12
E
F
D
G
H
B
C
BOX1 BOX2 BOX3
***NOTICE BEFORE ASSEMBLY***
Please choose the CHAISE will be on the LEFT or RIGHT hand side
BOBKONA
CHAISE ON THE RIGHT
BEFORE ASSEMBLY
PATENT PENDING #12/383.905; #12/460.021
ASSEMBLY INSTRUCTION FOR MODEL NO. : F7615, F7616, F7617, F7618, F7619, F7620
***PLEASE REMOVE ALL PARTS FROM SEAT FRAMES AND SEAT BACKS BEFORE ASSEMBLY***
Remove hardwares for chaise and sofa
from inside the seat backs.
*Cushions, pillow and legs included*Cushions, pillow and legs included
*Cushions and legs included
Open up the Velcro of Non-Woven Fabric cover
on the bottom of the seat frame to remove seat
cushions, back cushions and pillow
Before assembly, open
both Box 1 and Box 2 to
switch between Part C
and Part F. And you will
get the direction of right
chaise.
Control No.
