Body Solid FUSION 500 - Page 6

D i m e n s i o n s
The room layout diagram below will help you decide the best placement for your Fusion 500.
The dimensions of the Fusion 500 are: width 3’ 11” X length 6’ 4”.
The ceiling height requirement for the Fusion 500 is 6’ 18”.
The usage space is: width 6’ X length 10’ (The usage space is the overall space needed for operation.)
The usage space needed for the Fusion 500 could be more, depending if the user allows enough room for the
Low Row Station.
5
The room layout diagram below will help you decide the best placement for your F600.
The dimension of the F500 are: width3'11" X length 6' 4".
The ceiling height requirement for the F500 is 6' 18".
The usage space is: width 6') X length 10' (The usage space is the overall space needed for operation.)
The usage space needed for the F500 could be more,depeding if the user allows enough room for the Low Row Station.
D i m e n s i o n s
Dimensions
Height
Suggested usage space
1893mm
6'2"
1212mm
3'11"
2091mm
6'10"
3048mm
10'
1829mm
6 '
