6
S T E P
1
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step unless otherwise noted.
Some components may be pre-assembled
A. Connect Bottom Frame (20) to Rear Bottom Frame (7)
GPR378
using:
Two 13 (12*100mm hex head bolt)
Four 15 (12mm washer)
Two 14 (12mm nylon nut)
B. Thread T-Shaped Pop Pin (44) into Bottom Frame (20).
C. Insert End Cap (16) and Foot Caps (17) into Bottom Frame (20) as shown in the
diagram.
D. Insert Rubber Covers (41) onto the hooks of Bottom Frame (20).
