8
S T E P
2
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step unless otherwise noted.
Some components may be pre-assembled
A. Place 3/4” Rubber Donuts (49) onto the welded risers on Bottom Frame (20).
B. Slide Guide Rods (27) through 3/4” Rubber Donuts (49) and the welded risers on
Bottom Frame (20).
C. Slide Weight Stack Plates (64) onto Guide Rods (27).
D. Slide 1” Rubber Donuts (51) onto the weight horns on Top Plate (24).
E. Connect Top Plate (24) to Selector Rod (28) by using:
One 60 (10*45mm socket head bolt)
One 61 (10mm spring washer)
F. Thread Selector Rod Top Bolt (29) into Selector Rod (28) using:
One 30 (12mm nut)
One 63 (12mm spring washer)
To Next Page
